Goods Hoist | Goods Lift Manufacturer

Customized dumbwaiter for easier food lifting

Installing goods hoist for hoisting industrial machines and heavy products

Standard load is 2000kg

3 storey goods hoist installation. Lifting goods from floor to floor

Customised lift and goodshoist to fit your product sizes

installation

Space Requirement

The standard size requirements below can be utilized when the standard features are acceptable parameters for the project. If you ahve special site conditions, many options, or would like a custom drawing for your project, visit the Solutions Center at www.mlleedind.com.my where a customized drawing can be produced for you within a day.



Floor Loading Intended for loading material with a cart or at floor level		Table Loading Intended for hand loading material


Single Opening All same direction		Opposite Opening Front and rear opening

50KG - 500KG

Model	Total Capacity	Car			Entrance		Serving Height	Shaft		Pit Depth	Headroom
Model	Total Capacity	Width	Depth	Height	Width	Height	Serving Height	Width	Depth	Pit Depth	Headroom
DW50	50-100kg	610	760	760	320§	770	750	1070	950	-	1520
DW200	200kg	610	760	760	420§	770	750	1200	1200	-	1520
